TẤM PIN CANADIAN 440wp

Thông tin mô tả:

26 % more power than
conventional modules
Low NMOT: 42 ± 3 °C
Low temperature coefficient (Pmax):
-0.36 % / °C
MORE RELIABLE
Up to 4.5 % lower LCOE
Up to 2.7 % lower system cost
Heavy snow load up to 5400 Pa,
wind load up to 3600 Pa*
42°C
Better shading tolerancehttp://www.vicoexport.com/wp-content/uploads/2020/01/Canadian-Solar-Datasheet-HiKu_CS3W-MS_Super-High-Power_v5.585_EN_425-450-Vico-Export-Solar-Energy.pdf

Địa chỉ:387/32 đường Âu Cơ, P. Hòa Khánh Bắc, Q. Liên Chiểu, TP.Đà Nẵng
Hotline: 0988.408.923 – 0968.089.218

Mã: CAN440 Danh mục: TẤM PIN MẶT TRỜI Từ khóa: pin canadian 370w, pin jinko 400w, pin jinko 405w, Pin năng lượng mặt trời

Mô tả
Đánh giá (0)

Cell Type Mono-crystalline
Cell Arrangement 144 [2 X (12 X 6) ] Dimensions 2108 X1048 X40 mm (83.0 X41.3 X1.57 in)
Weight 24.9 kg (54.9 lbs)
Front Cover 3.2 mm tempered glass
Frame Anodized aluminium alloy, crossbar enhanced
J-Box IP68, 3 bypass diodes
Cable 4 mm2 (IEC), 12 AWG (UL)
Cable Length (Including Connector)
Portrait: 500 mm (19.7 in) (+) / 350mm (13.8 in) (-); landscape: 1400 mm
(55.1 in); leap-frog connection: 1670mm (65.7 in)*
Connector T4 series or H4 UTX or MC4-EVO2
Per Pallet 27 pieces
Per Container (40′ HQ) 594 pieces
